Drip Coffee Bag Packing Machine
categories
new products
C19H PLA Biodegradable Filters for drip coffee bag packing machine We promise 1:On - site repair 2:Free one-year warranty 3:Free testing machine 4:Free operating machine training more
C88DX Automatic PLA tea packing machine(Bag type) pyramids herbal tea bag packing machine with thread,Automatic Nylon Pyramid/Flat Inner and Outer Bag Packing Machine more
C28DX Automatic Nylon Triange/Flat small tea sachet packing machine pyramids herbal tea bag packing machine with thread,Automatic Nylon Pyramid/Flat Inner and Outer Bag Packing Machine more
C25 pyramid/flat bag film tagging machine PLA tagging machine more
coffee bagging machine，coffee pouches packing machine
item no.:
C19Klead time:
30 Business Days After Deposit Arrivedproduct orgin:
chinabrand:
SENGONGshipping port:
xiamen portpayment:
BY T/T Or L/Ccolor:
as picture
cotton thread
cotton thread
cotton thread
Nylon mesh filters
filter paper
nylon tea bag packaging label
PET mesh for tea bag
nylon tea bag packaging label
Non-woven fabric filters
PLA Biodegradable Filters
Drip Coffee Filters
Nylon mesh filters
Application:
It is suitable for 5 to 15gram drip coffee inner and outer bag packaging.
Features:
1. Outer bag sealing is controlled by the stepper motor, ensuring accurate and stable bag length positioning.
2. Adopts PID temperature controller for more accurate temperature adjustment.
3. Adopts PLC control system and touch screen color monitor device, machine is very easy to operate.
4. The main machine parts is made of SUS304 stainless steel, so it ensures hygiene products output.
5. Some cylinders are imported, ensuring the accuracy and stability of the machines’ performance.
6. It can make the inner and outer bag at the same time automatically, which would highly improve the working efficiency.
7. Adopts automatic conveyor system.
8. Options: Date code printer.
9. There is a reserved connector to link with nitrogen making machine so as to flush nitrogen into the bag to extend its shelf life.
10. Adopts high specifications components.
Standard Technical Data
| Type | Drip Coffee Packaging Machine Series |
| Model | C19K |
| Product name |
C19K Ultrasonic drip coffee machine packets |
| Bag type | Ultrasonic sealing |
| Packing material | Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper |
| Feeding system | Volumetric cup filler |
| Package range | 5-15g |
| Inner bag size | L:50-75mm , W:50-90mm |
| Outer bag size | L:85-120mm , W:75-100mm |
| Inner bag film width (180mm) | Bag size: L90mm*W75mm |
| Outer bag film width(200mm) | Bag size: L120mm*W100mm |
| Power supply | Single phase, 220V, 50HZ, 3.7KW |
| Packing speed | 30-60bags/min |
| Weight | 550KG |
| Dimension (L*W*H) | 1200*900*1900mm |
Manufacturer of a wide range of Packaging Machine,which include Coffee Pouch Packing Machine,coffee bagging machine,etc.
previous :
C19K coffee pouch filter sealing machinenext :
C19II Automatic Drip coffee packaging machine for saleWe will contact you as soon as possible!
