Application: weigh and fill machine Robusta coffee machine is suitable for 5 to 15gram drip coffee inner and outer bag packaging. Features: 1.Outer bag sealing is controlled by the stepper motor, ensuring accurate and stable bag length positioning. 2.Adopts PID temperature controller for more accurate temperature adjustment. 3.Adopts PLC control system and touch screen color monitor device, machine is very easy to operate. 4. The main machine parts is made of SUS304 stainless steel, so it ensures hygiene products output. 5. Some cylinders are imported, ensuring the accuracy and stability of the machines’ performance. 6. It can make the inner and outer bag at the same time automatically, which would highly improve the working efficiency. 7. Adopts automatic conveyor system. 8. Options: Date code printer. 9. There is a reserved connector to link with nitrogen making machine so as to flush nitrogen into the bag to extend its shelf life. 10. Adopts high specifications components.
Standard Technical Data
Type
Drip Coffee Packaging Machine Series
Model
C19K
Product name
C19K Automatic drip coffee filling and sealing machine
Bag type
Ultrasonic sealing
Packing material
Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper
Feeding system
Volumetric cup filler
Package range
5-15g
Inner bag size
L:50-75mm , W:50-90mm
Outer bag size
L:85-120mm , W:75-100mm
Inner bag film width (180mm)
Bag size: L90mm*W75mm
Outer bag film width(200mm)
Bag size: L120mm*W100mm
Power supply
Single phase, 220V, 50HZ, 3.7KW
Packing speed
30-60bags/min
Weight
550KG
Dimension (L*W*H)
1200*900*1900mm
1:whether sengong have their own machine and warehouses? Yes,we are professional factory special in tea,coffee,food packing machine over 16 years, We have own engineers and warehouses:
2:How about sengong products quality? we provide our clients with high quality pyramid tea bag packing machine ,and believe the quality is our products heart,Have already passed SGS testing, ISO9001:2008 quality system certification,BV certification and CE certificates of EU. 3: Whether the packing machine can keep the tea taste when packing into bag? Please don't worry ,will not influence your tea taste, the machine use the ultrasonic seal method,will maintain the pure the taste of tea,or flower tea, herbal tea etc. 4:What can i do while some trouble with the purchase packing machine ? We have a perfect aftersales service guarantee system,staffed with experience technicians,engineers,and managerial persoal,our after-sales service department has always been providing"quality,rapid and efficient service for all customers
